Hello, when I print a Pie Chart in a PDF, there is no text, either for the legend, or for the "pie slice" percentages.

Any suggestions?





Example of a pie chart from a PDF:

The most basic information is missing: Which LS version? Without that, it will be very difficult to reproduce.

Forgot...

Version 3.7.1+180424
Chrome Browser
Ubuntu 16.04 installation

Also, here's what I get when I hover over the pie chart.

Got the same problem here, did you solve it?

holch wrote: The most basic information is missing: Which LS version? Without that, it will be very difficult to reproduce.

Version: 3.14.5

I did some changes in the code and now I can show the legend, but they're wrong and still no percentage in any slice.


Edit: the legend isn't wrong but I would like to show the question text in the place of the numbers.

Edit2: I just figure out how to make the percentages work, in limesurvey\application\helpers\admin\statistics_helper.php where the 3D pie chart is created the "setFontProprieties" was poiting to '$rootdir."/fonts/".$chartfontfile', but the fonts are in '$rootdir."/assets/fonts/".$chartfontfile'. Now I just need to change te text.

Just a question, the option "graph type" was supposed to work just when i select html format or for pdf too? Because it doesn't, the graph type shown is the one i've set when creating the question.

Edit2: I just figure out how to make the percentages work, in limesurvey\application\helpers\admin\statistics_helper.php where the 3D pie chart is created the "setFontProprieties" was poiting to '$rootdir."/fonts/".$chartfontfile', but the fonts are in '$rootdir."/assets/fonts/".$chartfontfile'. Now I just need to change te text.

Update to the latest version, see if the problem persists. If it persists: make a bug report. Your changes might be overwritten by any future update you might make, so I think it is best that it is fixed in the core, rather than you hacking the code. Might be a temporary solution, but is not future proof.

So a year later I still have the same issue! Thankfully, I found the problem, and set up a workaround.

ISSUE: PDF legends on pie graphs and other graphs have no text. I found the problem by setting debug to "2" in the config.php file. This showed a number of PHP warnings linked to pChart.class.php and specifically a link to a missing file found along the path /HOMEDIR/fonts/DejaVuSans.ttf. It turns out that there is no fonts folder in this location, but there is one along the path /HOMEDIR/assets/fonts/DejaVuSans.ttf. I'm guessing this is because I have upgraded (properly) a number of times, and somehow the MySQL database still has a reference to the old path.

WORK AROUND: For now, I just created a symbolic link so that /fonts points to /assets/fonts. At some later date, perhaps I'll track down the error in the database.

NOTE: This seems somehow related to this bug report: bugs.limesurvey.org/view.php?id=13338

My current LimeSurvey version 3.16.1+
